UV2513 Large Format UV Flatbed Printing Machine For Ceramic Tile Wood
Characteristics:
* 2.5m platform width to ensure that the carriage can speed up when printing, thus avoid speed problem caused by the short distance of x-axis.
* Large size Adsorption Vacuum table can makes the soft materials being flat and absorbed on the table tightly to make sure the printing quality
* 2.5 liter volume big ink tank can make sure the printer can keep printing for a long time without load ink frequently
* High-precision Japanese THK linear guide makes printing in high precision
* Self-protection system of print head circuit use optical fiber transmission to make the printing smooth and uninterrupted
* The carriage lead by screw and double linear guide to keep the print head and the material be horizontal and vertical
* Enough nuts to adjustment the precise horizontal and vertical height of the large printer platform
* We can adjust the brightness of the UV LED lamp according to your requirements through this part
* Double UV LED Lamps to make the ink dry faster and make the printing area bigger to realize industrial large format printing
* Double DX7 heads high quality colorful picture printing with Focus ICC printing profile
Product parameters:
| Model | UV2513 Large Format UV Digital Inkjet Printing Machine For Ceramic Tile Wood |
| LED-UV Function | UV lamp system | 6 Power degree adjustable system |
| UV Power | 100W |
| UV lamp life time | 50000hours |
| UV light wavelength | 390-400nm |
| Light power | 500mw/w |
| Cooling type | Water circulation |
| Cooling adjustment | Automatic on/off between 25-30c |
| Control Software | FocusRIP-UV V3.5.0 |
| Repeat printing precision | Overlap small than 0.1mm |
| Head maintain | Head clean during/after printing, Keep-wet system when idle. |
| Ink system | Automatically Ink damper refill system |
| Max. printing size | 2500mm*1300mm |
| Print head | One or Double DX5/DX7 piezo head with 1440 nozzles |
| Print color | 2*(CMYK+WWWW) |
| Print direction | Unidirection / Bidirection |
| Print speed | A2(1440dpi)/ 120s |
| Max. media thickness | 150mm |
| Max. media weight | 15KG |
| Max. printing resolution | 2880DPI*1440DPI*7200DPI*360DPI |
| Ink volume | 150ML |
| Ink type | UV environmentally ink |
| Height adjustable | Manual / Automatic |
| Print head protection | Intellective automatic detect |
| Working power | 110-220V 50-60HZ 75W |
| Interface | USB2.0 /IEEE1394 |
| System require | Windows XP / Vista/ Win7 / MAC I Linus |
| Working enviroment | 25-30C, 50% Humidity, Dust free |
| Net weight/Gross weight | 780KG/850KG |
| Printer size | 370CM*175CM*115CM |
| Packing size | 410CM*220CM*1600CM |
Machine Configuration:
Applications:
Acrylic,Aluminiums model boards,Wood board,Ceramic tile,Foamboard,Sheet metal,Glass,Cardboard and other flat object.
Our service:
1. The company who initially provide 2 years warranty in the world,
2. 24-hour full after sales service.
3. All finished machine we delivered are 100% strictly tested by our QC department and engineering department.
4. OEM Service Customized and OEM orders are welcome due to our abundant experiences. All the OEM services are free.
